Light steel frame house
Light steel frame house, also known as LGSF. With cold-formed thin-walled steel members as the basic structural skeleton, new-type structural plates as the structural system, and other thermal insulation and decorative materials, the house construction system is formed through factory integrated production and on-site assembly. The system adopts cold-formed thin-walled steel structure system, which has the characteristics of small cross-sectional size and light weight. Compared with traditional buildings, the usable area is increased by 5-10%, and the basic cost is significantly reduced; Rich in lightness and dynamics, it improves the flexibility of the interior layout;
low-carbon and environmentally friendly building materials make the building more durable and the structure safer, and has good earthquake resistance, fire protection, thermal engineering, and sound insulation performance. It is a high-efficiency Energy-saving green building system.
Advantages of light steel frame houses
Durability
More than 50 years of service life; Snow resistance performance: 1.55 kN/㎡ basic snow pressure; Fire resistance performance: different designs can reach 1-4 hours; Seismic performance: 9 degree fortification ( basic earthquake acceleration 0.4g).
Wind resistance performance
The basic wind pressure of 0.85kN/㎡, the wind speed of 209km/hr; Sound insulation performance: the sound insulation of the outer wall ( 200 mm thick wall) is 65dB, and the sound insulation of the inner wall (double-sided double-layer 9.5mm gypsum board, 181 mm wall) is the sound volume is 44dB.
Ventilation performance
The combination of natural ventilation and air supply ensures that the indoor air is fresh and clean, and the fresh air volume is greater than 15%.
Impact resistance of exterior walls
Concentrated impact load of 250kg.
Thermal insulation performance
The thermal resistance value of the 200mm thick wall is 4.24K•㎡/W, and its thermal insulation performance is twice that of the 490mm thick porous block brick.
Project Case
The purpose of Solidhome’s services is to provide customers with more technologically advanced light steel framed houses that are easy to assemble, safe and reliable.
